Series K30 - Pneuma shut-off valves 2/2-way

The Pneuma shut-off valves series K30 are 2/2-way valves and are used as an alternative to the Pneuma ball valves. They are available as single or double-acting versions and in sizes from 3/8'' to 2''. On request, the valves can be equipped with electrical position sensing and are also available with FKM or EPDM seals. The range of application extends from low vacuum up to 10 bar. The valve body is made of nickel-plated brass or stainless steel as required.
to product variants

material brass nickel-plated stainless steel
types 2/2-way valve NC - NO -D
operating pressure -0.97 to +10 bar 0 to 16 bar
control pressure 3.0 bar to 8 bar double acting type = D)
4.2 bar to 8 bar (single acting type NC/NO)
temperature 0°C up to +80°C
(-20°C up to +80°C with dry air) 		-20°C up to +150°C
control media filtered compressed air (oiled or unoiled)
body brass 58 nickel-plated stainless steel
piston brass 58 chemically nickel-plated stainless steel
seals NBR - alternatively FKM, EPDM FKM
O-rings shaft NBR - alternatively FKM, EPDM FKM
O-rings piston NBR - alternatively FKM, EPDM FKM
springs spring steel
compression seal NBR - alternatively FKM, EPDM FKM
sleeve brass 58 nickel-plated stainless steel
seal seat brass 58 nickel-plated stainless steel
washer stainless steel
nut stainless steel
size G3/8" up to G2" G3/8" up to G2"
thread BSP
medium gases liquids, rough vacuum viscous or corrosive media
interface NAMUR
K-PNS-100D-MSv-NBR - 2-2 way pneumatic shut-off valve
K-PNS-100D-MSv-NBR - 2-2 way pneumatic shut-off valve
3 articles
K-PNS-300D-MSv-NBR - 2/2-way pneuma shut-off valve - double acting
K-PNS-300D-MSv-NBR - 2/2-way pneuma shut-off valve - double acting
7 articles
K-PNS-101D-MSv-FKM - 2-2 way pneumatic shut-off valve
K-PNS-101D-MSv-FKM - 2-2 way pneumatic shut-off valve
1 articles
K-PNS-301D-MSv-FKM - 2/2-way pneuma shut-off valve - double acting
K-PNS-301D-MSv-FKM - 2/2-way pneuma shut-off valve - double acting
7 articles
K-PNS-102D-MSv-EPDM - 2-2 way pneumatic shut-off valve
K-PNS-102D-MSv-EPDM - 2-2 way pneumatic shut-off valve
1 articles
K-PNS-302D-MSv-EPDM - 2/2-way pneuma shut-off valve - double acting
K-PNS-302D-MSv-EPDM - 2/2-way pneuma shut-off valve - double acting
7 articles
K-PNS-110NG-MSv-NBR - 2-2 way pneumatic shut-off valve
K-PNS-110NG-MSv-NBR - 2-2 way pneumatic shut-off valve
4 articles
K-PNS-310NG-MSv-NBR - 2/2-way pneuma shut-off valve - single acting NC
K-PNS-310NG-MSv-NBR - 2/2-way pneuma shut-off valve - single acting NC
7 articles
K-PNS-111NG-MSv-FKM - 2-2 way pneumatic shut-off valve
K-PNS-111NG-MSv-FKM - 2-2 way pneumatic shut-off valve
3 articles
K-PNS-311NG-MSv-FKM - 2/2-way pneuma shut-off valve - single acting NC
K-PNS-311NG-MSv-FKM - 2/2-way pneuma shut-off valve - single acting NC
7 articles
K-PNS-312NG-MSv-EPDM - 2/2-way pneuma shut-off valve - single acting NC
K-PNS-312NG-MSv-EPDM - 2/2-way pneuma shut-off valve - single acting NC
7 articles
K-PNS-120NO-MSv-NBR - 2-2 way pneumatic shut-off valve
K-PNS-120NO-MSv-NBR - 2-2 way pneumatic shut-off valve
1 articles
K-PNS-320NO-MSv-NBR - 2/2-way pneuma shut-off valve - single acting NO
K-PNS-320NO-MSv-NBR - 2/2-way pneuma shut-off valve - single acting NO
7 articles
K-PNS-121NO-MSv-FKM - 2-2 way pneumatic shut-off valve
K-PNS-121NO-MSv-FKM - 2-2 way pneumatic shut-off valve
1 articles
K-PNS-321NO-MSv-FKM - 2/2-way pneuma shut-off valve - single acting NO
K-PNS-321NO-MSv-FKM - 2/2-way pneuma shut-off valve - single acting NO
7 articles
K-PNS-322NO-MSv-EPDM - 2/2-way pneuma shut-off valve - single acting NO
K-PNS-322NO-MSv-EPDM - 2/2-way pneuma shut-off valve - single acting NO
7 articles
K-PNS-211NO-VA-FKM - 2/2-way pneuma shut-off valve - single acting NO
K-PNS-211NO-VA-FKM - 2/2-way pneuma shut-off valve - single acting NO
7 articles
K-PNS-211NG-VA-FKM - 2/2-way pneuma shut-off valve - single acting NC
K-PNS-211NG-VA-FKM - 2/2-way pneuma shut-off valve - single acting NC
7 articles
K-PNS-201D-VA-FKM -2/2-way pneuma shut-off valve - double acting
K-PNS-201D-VA-FKM -2/2-way pneuma shut-off valve - double acting
7 articles
VAZ-NAM-MIF520 - 5/2-way Namur solenoid valve
VAZ-NAM-MIF520 - 5/2-way Namur solenoid valve
3 articles
VAZ-NAM-MII520 - 5/2-way Namur solenoid valve
VAZ-NAM-MII520 - 5/2-way Namur solenoid valve
3 articles

Choose your Product Variant

Filter

Active Filters:

VAZ-NAM-MIF520-1/4
AZ582ME

5/2-way solenoid valve Namur

VAZ-NAM-MIF520-1/4
Valve actuation: impulse Valve design: 5/2 way Valve type: Solenoid valve
Special Characteristics: 5/2-way solenoid valve Namur with spring return - pilot operated
Product Specific Download:
Catalogue

Price per piece

€78.65*

Available

VAZ-NAM-MII520-1/4
AZ582EE

5/2-way Namur solenoid valve

VAZ-NAM-MII520-1/4
Valve actuation: impulse Valve design: 5/2 way Valve type: Solenoid valve
Special Characteristics: 5/2-way Namur solenoid valve with pulse control - pilot-operated
Product Specific Download:
Catalogue   CAD

Price per piece

€104.48*

Available in 15 days, delivery time 1-3 days

K-PNS-321NO-3/8-MSv-FKM
20210071

2/2-way pneumatic shut-off valve - single-acting

K-PNS-321NO-3/8-MSv-FKM
Valve design: 2/2 way Valve neutral position: NO material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally open without Namur i…
Product Specific Download:
Catalogue

Price per piece

€179.30*

Delivery date upon request

K-PNS-121NO-3/8-MSv-FKM
20250058

2/2 way axial valve 3/8"

K-PNS-121NO-3/8-MSv-FKM
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2 way axial valve 3/8" single-acting normally open, with Namur interface full…

Price per piece

€179.32*

Available

K-PNS-201D-3/8-VA-FKM
20250111

2/2-way pneumatic shut-off valve - double-acting

K-PNS-201D-3/8-VA-FKM
max. operating pressure: 10 max. temperature: 150 min. temperature: -20
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting with Namur interface Materia…
Product Specific Download:
Catalogue

Price per piece

€215.94*

Available

K-PNS-211NG-3/8-VA-FKM
20250121

2/2-way pneumatic shut-off valve - single-acting

K-PNS-211NG-3/8-VA-FKM
max. operating pressure: 10 max. temperature: 150 min. temperature: -20
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally closed; with Namur i…
Product Specific Download:
Catalogue

Price per piece

€215.94*

on request (phone / email)

Details
K-PNS-311NG-3/8-MSv-FKM
20210051

2/2-way pneumatic shut-off valve - single-acting

K-PNS-311NG-3/8-MSv-FKM
Valve design: 2/2 way Valve neutral position: NC material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally closed without Namur…
Product Specific Download:
Catalogue

Price per piece

€179.30*

Available

K-PNS-211NO-3/8-VA-FKM
20250131

2/2-way pneumatic shut-off valve - single-acting

K-PNS-211NO-3/8-VA-FKM
max. operating pressure: 10 max. temperature: 150 min. temperature: -20
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally open; with Namur int…
Product Specific Download:
Catalogue

Price per piece

€215.94*

on request (phone / email)

Details
K-PNS-312NG-3/8-MSv-EPDM
20210061

2/2-way pneumatic shut-off valve - single-acting

K-PNS-312NG-3/8-MSv-EPDM
Valve design: 2/2 way Valve neutral position: NC material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally closed without Namur…
Product Specific Download:
Catalogue

Price per piece

€179.30*

Delivery date upon request

K-PNS-300D-3/8-MSv-NBR
20210001

2/2-way pneumatic shut-off valve - double-acting

K-PNS-300D-3/8-MSv-NBR
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting without Namur interface - ful…
Product Specific Download:
Catalogue

Price per piece

€145.90*

Available

K-PNS-302D-3/8-MSv-EPDM
20210041

2/2-way pneumatic shut-off valve - double-acting

K-PNS-302D-3/8-MSv-EPDM
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting without Namur interface - ful…
Product Specific Download:
Catalogue

Price per piece

€164.10*

Delivery date upon request

K-PNS-301D-3/8-MSv-FKM
20210031

2/2-way pneumatic shut-off valve - double-acting

K-PNS-301D-3/8-MSv-FKM
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting without Namur interface - ful…
Product Specific Download:
Catalogue

Price per piece

€164.10*

Delivery date upon request

K-PNS-310NG-3/8-MSv-NBR
20210011

2/2-way pneumatic shut-off valve - single-acting

K-PNS-310NG-3/8-MSv-NBR
Valve design: 2/2 way Valve neutral position: NC material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally closed without Namur…
Product Specific Download:
Catalogue

Price per piece

€161.00*

Available

K-PNS-100D-3/8-MSv-NBR
20250001

2/2-way pneumatic shut-off valve - double-acting

K-PNS-100D-3/8-MSv-NBR
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting with Namur interface - full b…

Price per piece

€145.91*

on request (phone / email)

Details
K-PNS-320NO-3/8-MSv-NBR
20210021

2/2-way pneumatic shut-off valve - single-acting

K-PNS-320NO-3/8-MSv-NBR
Valve design: 2/2 way Valve neutral position: NO material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally open without Namur i…
Product Specific Download:
Catalogue

Price per piece

€161.00*

Delivery date upon request

K-PNS-101D-3/8-MSv-FKM
20250031

2/2-way pneumatic shut-off valve - double-acting

K-PNS-101D-3/8-MSv-FKM
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2-way pneumatic shut-off valve - double-acting with Namur interface - full b…

Price per piece

€164.08*

on request (phone / email)

Details
K-PNS-322NO-3/8-MSv-EPDM
20210081

2/2-way pneumatic shut-off valve - single-acting

K-PNS-322NO-3/8-MSv-EPDM
Valve design: 2/2 way Valve neutral position: NO material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally open without Namur i…
Product Specific Download:
Catalogue

Price per piece

€179.30*

Delivery date upon request

K-PNS-110NG-3/8-MSv-NBR
20250011

2/2 way axial valve 3/8"

K-PNS-110NG-3/8-MSv-NBR
Valve design: 2/2 way material: brass nickel-plated max. operating pressure: 10
Special Characteristics: 2/2 way axial valve 3/8" single-acting normally closed with Namur interface ful…
Product Specific Download:
CAD

Price per piece

€161.00*

Available

K-PNS-321NO-1/2-MSv-FKM
20210072

2/2-way pneumatic shut-off valve - single-acting

K-PNS-321NO-1/2-MSv-FKM
Valve design: 2/2 way Valve neutral position: NO material: brass nickel-plated
Special Characteristics: 2/2-way pneumatic shut-off valve - single-acting normally open without Namur i…
Product Specific Download:
Catalogue

Price per piece

€197.50*

Delivery date upon request

K-PNS-211NG-1/2-VA-FKM
20250122

2/2 way pneumatic check valve - single acting

K-PNS-211NG-1/2-VA-FKM
max. operating pressure: 10 max. temperature: 150 min. temperature: -20
Special Characteristics: 2/2 way pneumatic check valve - single acting normally closed, with Namur inter…
Product Specific Download:
Catalogue

Price per piece

€263.44*

Available in 13 days, delivery time 1-3 days
